Product Specifications

• Microprocessors and Bus Clock Frequency
  • MPC7400 @400 MHz Internal Clock Frequency

  • MPC750 @450 MHz Internal Clock Frequency

  • Bus Clock Frequency up to 100 MHz

• L2 Cache (Optional)
  • 1MB (MPC750) or 2MB (MPC7400) using burst-mode

  SRAM modules

• Memory
  • EEPROM, on-board programmable

  • 1MB via two 32-pin PLCC/CLCC sockets;

  16MB Surface Mount

• Main Memory (SDRAM)
  • PC100 ECC SDRAM with 100 MHz bus

  • 32MB to 512MB on board, expandable to

  1GB via RAM500 memory mezzanine

• NVRAM
  • 32KB (4KB available for users)

• Memory Controller
  • Hawk System Memory Controller (SMC)

• Manufactured by Motorola.

• Used in Good condition.

  Alternative Part No. RAM500-004, RAM500 004, rAM500, RAM 500

Product Manual

RAM500.pdf
