Product Specifications

• Up to 2.20 GHz Pentium® 4 Processor - M with 512 Kbyte advanced transfer cache

• Up to 1 Gbyte PC1600 DDR SDRAM using one SODIMM

• Internal SVGA and DVI controller

• 400 MHz system bus via Intel® 852GM chipset

• One Ethernet controller supporting 10BaseT and 100BaseTX interfaces

• One Ethernet controller supporting 10BaseT, 100BaseTX and 1000BaseT interfaces

• Front panel Universal Serial Bus (USB) connection Rev. 2.0

• Up to 1 Gbyte bootable flash on secondary IDE

• PMC expansion site

• Operating system support for Windows XP, Windows 2000, VxWorks, QNX, LynxOS, and Linux

Manufactured by GE Fanuc. New condition.

The GE Fanuc VMIVME7805 is an Intel Pentium 4 Processor-M-Based VMEbus Single Board Computer. The microprocessor brings the Intel Pentium 4 Processor - M to VME, offering processor speeds up to 2.2 GHz. The Intel Pentium 4 Processor - M is the first Intel mobile processor with the Intel NetBurst™ microarchitecture. The Intel Pentium 4 Processor - M utilizes a 478-pin, Micro Flip-Chip Pin Grid Array (Micro-FCPGA) package, and plugs into a surface mount, Zero Insertion Force (ZIF) socket. The Intel Pentium 4 Processor - M maintains full compatibility with IA32 software. The Intel NetBurst microarchitecture features include hyper-pipelined technology, a rapid execution engine, a 400 MHz system bus, and an execution trace cache. The hyper-pipelined technology doubles the pipeline depth in the Intel Pentium 4 frequencies. The rapid execution engine allows the two integer ALUs in the processor to run at twice the core frequency, which allows many integer instructions to execute in 1/2 clock tick. The 400 MHz system bus is a quad-pumped bus running off a 100 MHz system clock, making 3.2 Gbyte/s data transfer rates possible.

SKUE36

Qty 2

Alternative Part Number: VMIVME7805, VMIVME 7805 , VMIVME-7805, VME-7805,VME7805, VME 7805, VMIVME7805 RC, VMIVME 7805 RC , VMIVME-7805 RC
