Product Specifications

• High-performance PowerPC Real-time

  Engine (6750-SSIO: with Extended I/O)

• PowerPC 750, 300/400 MHz, 1 MByte

  L2 cache; 233 MHz, 512 KByte L2 cache

• 16 to 256 MByte DRAM

  (SDRAM or EDO/ECC)

• 4 or 8 MByte User Flash, 512 KByte

  Boot Flash

• 10BaseT/100BaseTx Ethernet port (6750-SSIO: 10BaseT/100BaseTx Ethernet

  or AUI Ethernet, Fast Wide SCSI-2 port)

• Two serial ports (6750-SSIO: six serial ports)

• Two PMC slots (6750-SSIO: one PMC slot)

• Programmable watchdog

• Single slot design, VME64

The PowerCore-6750™ and 6750-SSIO™, two new boards in Force’s PowerCore™ product family, combine enhanced processor performance with the VME architecture. VMEbus modularity allows you to choose from dozens of hardware and software configurations, so you’ll adapt system designs to specific applications quickly and easily. You can also capitalize on the outstanding performance and throughput of the VME architecture, the world’s most widely used 32/64-bit bus architecture for embedded applications. You’ll focus on product enhancements instead of basic computing.

SKUE3

Qty: 1

Alternative Part No. PMC-SSIO, 6750-SSIO, PMCSSIO

,

Product Manual

PMC-SSIO-Daatasheet.pdf
PowerCore6750-UM.pdf
