Product Specifications

• Intel® Core™2 Duo processor LV,

1.5 GHz

• Intel Core Duo processor 1.66

GHz and 2.0 GHz

• Ultra compact, two slots

• Extensive software support

• Up to 4 Gbyte DDR2 SDRAM

(200MHz) with ECC

• Flash Drive or local UDMA2

(ATA33) 2.5” hard disk

• 2x SATA, RAID 0/1 capable

• Front/rear VGA up to 1280x1024,

rear DVI-I up to 1280 x 1024, 32

Mbyte RAM

• Two Gigabit Ethernet ports

10/100/1000 BaseT front or rear

optional

• Compliant to VITA31.1-2003

• One front Fast Ethernet port

• Two PMC extension slots, one 64-

bit/133 MHz and one 32-bit/33

MHz

• One XMC interface on request

• 2x serial I/O with FIFOs

RS-232/422/485 interface

• 4x USB 2.0 ports, two front and

two on rear

• Audio codec

• Watchdog, temperature sensors

• Optional –40 °C to +75 °C

• Optional conformal coating

• Customer specific, low cost

assembly versions

• RoHS compliant

Manufactured by SBS Technologies/GB/Abaco. New- Excellent.

The VP11 is a 6U VME64 CPU board with integrated dual core Intel Core 2 Duo Processor or Intel Core Duo Processor and dual Gigabit Ethernet channels. The Intel dual core processor includes two optimized execution cores in a single processor case. This enables execution of parallel threads or applications on separate cores with dedicated CPU resources. The VP11 supports a 32- and 64-bit processor architecture. The VP11 is designed to meet the requirements of markets such as automation, simulation/training, test and measurement, and others.

SKUE34

Qty 1

Alternative Part No. VP11, VP1107C26RF1

Product Manual

vp11_ds.pdf
