Product Specifications

• Dual or single CPUs in a single slot solution

• Motorola 68040/68060 architecture

  · 23-66 MHz CPU speeds

• 128 MB high-speed DRAM

• Up to 16 MB Flash

• 10/Base-T Ethernet

• Exclusive, high speed EZ-Bus mezzanine interface

• Full line of EZ-Bus mezzanine cards

The V452 provides you with either single or dual '060/'040 processors. It's exclusive EZ-Bus mezzanine system provides the highest-bandwidth mezzanine card interface available on a 68K CPU-based card. Synergy provides a full range of I/O modules upporting EZ-Bus. Features include single or dual 50/66 MHz 68060s or 25/33 MHz 68040s, 50% power reduction over other 68K boards, ruggedization options, up to 128 MB DRAM, up to 16 MB flash, Bellcore,Nynex compliance, 10Base-T Ethernet, VME64 extensions support, EMI and conformal coating options.

SKUE3

Qty: 6

Alternative Part No. V452, V 452, 0090-76133-A, V452, RF-2, V452B, V452-B, V452-D, V452D
