Product Specifications

• System performance boost with Nehalem micro-architecture

• New CPU core and chipset designs reduce power consumption

• Deployment risks lowered with extended-life board design

• Single-processor SHB delivers fast memory performance

• Scalable SHB easily supports dual- CPU upgrades

Manufactured by TRENTON Technology, Inc. Refurbished in good condition.

Trenton’s JXTS6966 SHB supports PICMG 1.6 server or graphics-class stems with either a x16 or two x8 PCI Express links on a PICMG 1.3 backplane. An additional x4 PCIe link and eight PCIe reference clocks are also supplied on edge connectors A & B of the SHB. Trenton’s optional IOB33 module can be used on the board to provide additional x1PCIe link to a backplane. The Trenton JXTS6966 automatically configures all of its PCIe links to operate as either PCIe Gen 2.0 or PCIe Gen 1.1 interfaces based on the type of PCI Express endpoints such as option cards, PCIe switches and bridge chips. The PCI Express auto-negotiation feature is fully supported on the SHB and enabling x1, x4, x8, x16 PCI Express cards.

Qty 16

Alternative Part No. TRENTON 92-506966-XXX ,TRENTON 92-506966, 92 506966, JXT6966

Product Manual

JXTS6966-Datasheet.pdf
