Product Specifications

• MPC7410 PowerPC® microprocessor

• AltiVec technology

• Latest high-performance PowerPlus III Architecture

• 2MB/1MB of L2 cache

• Up to 512MB on-board ECC SDRAM

• 32MB on-board flash

• 72-bit ECC memory controller ASIC

• Single-wide PMC with a 66/33 MHz PCI interface

• Optional 10/100BaseT Ethernet interface

• 64-bit PCI host bridge

• One asynchronous serial debug port

• Hardware DMA channel

• Four 32-bit timers

• Two watchdog timers

Manufactured by Emerson Network Power. Refurbished in good condition.

The Emerson PrPMC800 series processor PCI mezzanine card (PMC) is the ideal solution when time-to-market and flexibility are important. In addition to the highlighted features, this PMC module also includes a full-length heatsink, creating a CPU package capable of handling the thermal requirements of complex tasks. Processor PMC (PrPMC) modules provide a complete host CPU and memory subsystem to a base board full of PCI-based I/O controllers in a compact, rugged,I ndustry standard form factor. The PrPMC isolates the complexities of a high-speed CPU, cache and memory signals from application-specific hardware, enabling OEMs to focus on their market requirements while simplifying their product release. These modules also simplify CPU and memory upgrades in performance-driven embedded and telecom applications.

SKUE31

Qty 1

Alternative Part No. PrPMC8005E-1269, PrPMC8005E, PrPMC8005E 1269

Product Manual

PrPMC800-Datasheet-jbeb.pdf
