Product Specifications

• Technical Information : Jumpers, Connectors, and Memory IOB31 (64-xxx) IO and PCI Express Expansion Board

• IOB31 Front View-
  Keyboard P7, PS/2 Mouse P8
  Parallel Port P5
  Serial 1 P1
  Serial 2 P2
  Flopping drive P4

• IOB31 Back View-
  P6 I/O Expansion Card Connector
  PCI Express Edge Connector
  LPC47B427

The IOB31 is an I/O expansion module or board, frequently used in conjunction with Trenton System Host Boards (SHBs) and Backplanes. It provides additional Input/Output capabilities, such as supporting PS/2 keyboard functionality, within industrial computer chassis. The IOB31 module is used in specific backplanes (e.g., BPX6806) to enable certain PCIe slot configurations from a PICMG 1.3 System Host Board.

SKUE7

Qty: 45

Alternative Part No. 20-XX6475-001, 92-506474-XXXX, IOB31

Product Manual

IOB31-6474-xxx-DS.pdf
