Product Specifications

• Magnification: 0.50 ×

• Mount Type: C-mount (microscope side mounts onto Leica 37 mm / ISO 38 mm phototubes

• Design Type: Direct Image Projection (DIP)

• Microscope Compatibility: Leica Stereo Microscopes (including models like the S6 and S8 APO series)

• Parfocal: Precisely machined to maintain focus between the microscope and the TV/monitor.

• Low Profile: Positions the camera's CCD chip directly at the intermediate image plane to maximize stability.

• Wide Field of View: Provides a broader, clearer viewing area on the monitor compared to standard 1.0 × couplers.

• Stereo:
  MS5, MZ6, MZ8, MZ12, MZAPO, MZFL3, MZ16
  in 37mm port of new phototubes HU(446 174)
  video/phototube objective 1.0x (445 930)
  video/phototube objective H (445 931)

The Diagnostic Instruments / Spot Imaging Solutions D50MZC is a 0.50 × Direct Image Projection (DIP) C-mount coupler designed for use with 1/2" CCD cameras on Leica stereo microscopes.

It is highly regarded for its low-profile, parfocal design that produces flat field images.  D50MZC acts as an optical coupler, specifically designed to relay images accurately from Leica microscope phototubes to C-mount format digital cameras.

The functions as an embedded vision system. The camera is built directly into the drone's structural chassis and communicates with an internal single-board computer, relying on internal microcontrollers to handle continuous input signals.

SKUE5

Qty: 1

Alternative Part No. Leica 10445930, D10DMC, D63MZC

Product Manual

DIAGNOSTIC-INSTRUMENTS-D50MZC-DATASHEET.pdf
D50MZC-Datasheet-2.pdf
